Eahora Juliet (Green)
4 interest-free payments of $474.75
Buy what you love and split the cost. It’s easy and interest-free.
Add item(s) to your cart
Go to checkout and choose
Enter your debit or credit card information
Your first payment is taken when the order is processed and the remaining 3 are automatically taken every two weeks
See payment terms. A higher initial payment may be required for some consumers. CA residents: Loans made or arranged pursuant to a California Financing Law license.
ABOUT Juliet
Meet Juliet, designed for riders who want reliable and long last cycling. The best ebike battery made by EV-class safety standards with 48V 60Ah capacity. Ride for longer distances now, no more worrying about running out of power. Featuring a step-thru design frame crafted from high-quality steel, providing exceptional strength and durability.
WHAT'S IN THE PACKAGE
Delivered with 85% assembled:
Ebike & battery;
Original charger & adapator;
Front tire & Headlight;
Pedals, saddle & seat post;
Product manual;
Screws and tools for assembly.
OWNER Manuals
1/3 - Electronic System
1000W Brushless Motor
Enjoy the thrillness of new generation motor with 1000W rated and 1250W peak output. Max output 25A controller makes it easier than ever to ride up hills and tackle challenging terrain.
Torque: 90N.m
Gradeability: 30° -40°
2/3 - Electronic System
48V 60Ah Battery
The largest battery capacity ebike battery with EV-class safety to maximally extend your riding range. Revel in its superior energy density, minimal self-discharge, and unmatched security compared to traditional lithium-ion counterparts.
Throtte Mode Range: 78 - 84 Miles
PAS Mode Range: 110- 120 Miles
3/3 - Electronic System
Color LCD Display
Five-level pedal assist and equip twist throttle can achieve the same speed in electric mode. Featuring pushing mode and cruising mode make more functionality and usability during cycling.
Size and Geometry
Recommended Rider Height: 5'4" - 6'4" or 165CM - 195CM
Ⓐ - Total Length: 72.05" or 183CM
Ⓑ - Wheel Base: 48.8" or 124CM
Ⓒ - Seat Height: 32.3" - 40.2" or 82CM - 102CM
Ⓓ - Handlebar Height: 42.5" or 108CM
Ⓔ - Rim Diameter: 16.4" or 42CM
Ⓕ - Standover: 24.2" or 61.5CM
Ⓖ - Reach Distance: 26.8" or 68CM
Ⓗ - Chain Stay Length: 18.9" or 48CM
Ⓘ - Seat Angle: 74.7°
Ⓙ - Seat Tube Length: 10.6" or 27CM
Ⓚ - Bike Width: 28" or 71CM
Ⓛ - Top Tube Length: 23.6" or 60CM
Technical Specifications
To ensure uninterrupted suppluying and shipping, some parts may differ from those listed. Rest assured, our engineers rigorously test each component to guarantee quality and compatibility.
Bike Class
Class 3 ebike with throttle and pedal asssit functions.
Bike Weight
116lbs in total with the battery.
Range per Charge
78 - 84 miles on throttle mode. 110 - 120 miles on pas mode.
Payload Capacity
Recomend rider weight within 330lbs.
ELECTRONIC SYSTEM
ELECTRONIC SYSTEM
Motor
1000W DC hub motor, cassette; rated torque: 90N.M.
Battery
48V 60AH (2.88KWH) lithium battery.
Controller
48V, 25 ± 0.5A; 12MOS.
Charger
54.6V ~ 8A smart charger; input 100-240V 50/60HZ.
Display
4" portrait color display(YL-81F), IP65 Waterproof; brightness: 100CD/M2
Lights
Front light 48V LED light; rear intergrated brake lights, turn-signal lights.
Wiring
Water resistant connectors and wiring harness.
BICYCLE COMPONENTS
BICYCLE COMPONENTS
Frame
Steel; frame size: 20" * 15".
Brakes
180MM front and rear hydraulic disc brakes.
Brake Levers
Aluminum alloy comfort grip levers with motor cutoff switch.
Tires
20" * 4" CST tires; tire pressure marked on sidewall.
Fork
80MM travel mechanic suspension alloy fork, adjustable.
Rear Suspension
35MM TravelSpring suspension(HLT-100) * 2.
Chain
DG50 chain.
Crank Set
48T * 165MM, dual-sided chainring guard.
Shifters
Shimano 7-speed.
Derailleur
Shimano 7-speed.
Freewheel
Shimano 7-speed, 14-28T.
Grip
Comfort rubber ergo grips.
Handlebar
BMX handlebar.
Pedals
9/16, polymer bearing.
Headset
Intergrated threadless headset.
Rack
Customized steel rear rack.
Kickstand
Aluminum leg with durable plastic cover, adjustable.
Fenders
Snow tire fenders.
Saddle
Comfort leather saddle.
Rims
Aluminum 36H spoke wheel.
Seatpost
Aluminum seapost with clamp.
Bell
Integrated electric horn.
