Technical Specifications

*To ensure uninterrupted suppluying and shipping, some parts may differ from those listed.
Rest assured, our engineers rigorously test each component to guarantee quality and compatibility.

Basic

• Bike Class
• Class 3 ebike with 5-level pedal assist and throttle.

• Bike Weight
• 124.6 lbs in total with the battery. The battery weighs 27.6 lbs.

• Range per Charge
• 74 - 80 miles on throttle mode. 106 - 116 miles on pas mode.

• Payload Capacity
• Recomend rider weight within 330lbs.

Electronic System

• Motor
• 1000W DC hub motor, cassette; Torque: 90N.M.

• Battery
• 48V 60AH (2.88KWH) lithium battery.

• Controller
• 48V, 25 ± 1A; 12MOS.

• Charger
• 54.6V ~ 5A smart charger; input 100-240V 50/60HZ.

• Display
• 4" portrait color display(Mask), brightness: 100CD/M2

• Lights
• Front light with 48V 20W LED light, rear light with brake signal and turn signal blinker.

• Wiring
• Wiring harness with water-resistant connectors.

• Waterproof Rates
• IP65 Waterproof, including motor battery, display and wiring.

Bicycle Components

• Frame
• Carbon Steel; frame size: 26" * 18".

• Brakes
• 180MM front and rear hydraulic disc brakes, dual piston brake caliper.

• Brake Levers
• Aluminum alloy levers with motor cutoff switch.

• Tires
• 26" * 4" CST tires; tire pressure marked on sidewall.

• Fork
• 100MM travel hydraulic suspension alloy fork, adjustable.

• Rear Suspension
• 50MM adjustable air valve shock absorber.

• Chain
• T50 alloy steel rust-resistant chain; 126 segments.

• Crank Set
• 44T * 170MM, dual-sided chainring guard.

• Shifters
• Shimano 7 Speed(ASLTX50R7CT), 22.2MM * 2400MM.

• Derailleur
• Shimano 7 Speed(RD-TY300).

• Freewheel
• Shimano 7 Speed(MF-TZ500-7),14-28T.

• Grip
• Comfort rubber ergo grips.

• Handlebar
• Rise Handlebar, w 720 * φ 22.2.

• Pedals
• 9/16, polymer bearing.

• Headset
• Intergrated threadless headset.

• Rack
• Optional.

• Kickstand
• Aluminum alloy kickstand with plastic foot.

• Fenders
• Custom fat tire fenders, no bracket arm.

• Saddle
• Leather fabric, breathable, memory foam.

• Rims
• Aluminum spoke rims, 26" * 4" * 12G * 36H.

• Seatpost
• None.

• Bell
• Electric horn integrated into the headlight.
